EZ-RJ45 Cat 6 EZ-Term Modular Plug

BTX EZ-RJ45 Cat 6 connectors simplify twisted pair terminations by inserting the wires through the connector. Works on solid or stranded wire 23 AWG and 24 AWG.
$1.03 / EA
In Stock:
2182
BTX #:
CD-EZRJ456
Mfr. #:
CD-EZRJ456
Unit Size:
1
BTX CD-EZRJ456 RJ45 Cat 6 connector simplifies twisted pair terminations by inserting the wires through the connector and out the front. This allows easy verification of the proper wiring order. Electrical performance of the termination is optimized by pulling the connector down over the cable jacket and seating it tightly in the rear of the connector. By reducing the distance between the wire twists and contacts, performance is optimized. Connectors are clear/transparent with 50 micron gold plated contacts. Recommended crimp tool is TD-EZRJ45PROHD. Use with solid or stranded cable 24 AWG to 23 AWG, with maximum cable outer diameter of 0.275‚ (6.98mm) and maximum insulation diameter (conductors) of 0.040‚ (1.016mm). Meets ANSI/EIA/TIA/TAA specifications. UL Listed and RoHS/FCC compliant. Made in the USA.
More Information
Unit of MeasureEA
Unit Size1
Mfr.CD-EZRJ456
ManufacturerBTX Technologies
uomEA
AvailabilityIn Stock
